BT3002,BT2003,BT2002 series

British Standard 75 Ohm telecommunication cables, specially designed for digital telephone exchange and interconnection of telecommunication equipment, in a range of telecommunication systems. These cables are available in LSOH and PVC versions, in single or multi-core versions, to suit a range of applications and requirements.

Key Benefits

Excellent performance
Special design
Single/ Multi-core versions
Double braid
Easy for installation

Applications

Telecom systems
Digital telephone exchange
Interconnection of telecommunication equipment

Specifications:

Item	Descriptions	Approved Testing Band Mhz	Related Connectors
BT3002- single core	0.31mm BC conductor , 90% Double TC Braid , 3.55mm PVC Jacket, Standard Shield	1-200	BNC, SMB, 1.0/2.3 PLUG ,43/5FQT ,1.6/5.6 MALE CRIMP
BT3002- 8 core	0.31mm BC conductor , 90% Double TC Braid , 3.55mm PVC Jacket, 16.05mm Overall PVC Jacket	1-200	BNC, SMB, 1.0/2.3 PLUG ,43/5FQT ,1.6/5.6 MALE CRIMP
BT3002- 16 core	0.31mm BC conductor , 90% Double TC Braid , 3.55mm PVC Jacket, 19.60mm Overall PVC Jacket	1-200	BNC, SMB, 1.0/2.3 PLUG ,43/5FQT ,1.6/5.6 MALE CRIMP
BT2003- single core	0.61mm BC conductor , 90% Double TC Braid , 6.65mm PVC Jacket, Standard Shield	1-100	BNC CRIMP, 1.0/2.3 PLUG , 1.6/5.6 CRIMP ,
BT2002- single core	7*0.20mm BC conductor , 90% Double TC Braid , 5.10mm PVC Jacket, Standard Shield	1-200	BNC CRIMP ,SMZ, BMA
